NcStudio CNC Machine Vision Controller Software

Last Updated on Jan 17, 2024 by 5 Min Read
Weihong NcStudio CNC Controller V5.5.60 ENGLISH Setup

Weihong NcStudio CNC Controller V5.5.60 ENGLISH Setup

Weihong Ncstudio Machine Vision Controller

Weihong Ncstudio Machine Vision Controller

|-- PCI bus interface;

|-- Improved motion algorithm with better machining quality;

|-- Selectable Pulse output frequency,160KBit/s or 1MBit/s;

|-- Differential output/input signals with better reliability;

|-- CCD Auto positioning can eliminate error of installation and silk-screen;

|-- Extended boards with simpler wire connection;

|-- Expiration limit on hardware;

|-- Support functions of Advance Start, Breakpoint Resume, MPG Wizard, Reverse Cutting, and so on.

*Delivery against payment. The freight is excluded in the price.Swift code: MSBCCNBJ002

Motion Control Card
PCIMC-6AServo or Stepping
PCIMC-83AServo or Stepping
Axis
Maximum axis number3
Servo Driver Interface
Position signalPulse/direction
Signal typeDifferential
Pulse frequency160KBit/s
Encoder zero signalYes
Servo alarm signalYes
Servo enable signalYes
Extended Board (may vary with type of extended board)
Servo cableYes
Z-axis brake relayYes
Work-state lamp relayRed/Green Lamp
Zero limit input for each axisYes
External manual feed switchYes
External manual control switches for feedrate percent and origin-settingYes
External start/stop buttonsStart/Stop
V9 Software Features
Look aheadYes, intelligent
Maximum file size2G byte
Feedrate percent0 – 120%
Spindle rev. percent50 – 150%
SimulationYes
Operation modeAuto/Serial/Increment/MDI

/Reference point

Auto centreYes
Reverse cuttingYes
Auto open/close control valve in sequenceYes
open/close valve delayYes
Manual pulse generatorYes
Chinese themeEnglish/Chinese (switch)
CompensationBacklash/Lead screw/ Quadrant
File Formats
G codeYes
PLT formatYes, 2D and 3D
DXF formatYes
ENG formatYes
Others
Power supply24v DC for external I/O port

Weihong Ncstudio Machine Vision Controller V5.4.0

In the manufactory dialog box, we add the parameter of the spindle.We support the biggest speed of the spindle and the delay of start(stop).

We support the speed of the spindle: the memory of the speed of spindle and the clew of the spindle.

In the driver of pcimc3a, we add the handwheel support.

In the manufactory dialog box, we add the parameter of handwheel.

The position of the fixed calibrate block is found in the parameter.

We add "simulate" in the tool bar.

We add "direct locate" in the tool bar.

Close the limit of axis Y in the mode of swivel table.

We modify the condition instructions, so it is preciser for calibration and move-to-origin.

Weihong Ncstudio Machine Vision Controller V5.4.1

It is customization for the "programme manage" and extend name.

We improve the capablity of the file-load and file-unload.We add the clew of the schedule.

Weihong Ncstudio Machine Vision Controller V5.4.2

It supports fixed calibration and mobile calibration simultaneously.

We improve the short-cut keys.

Weihong Ncstudio Machine Vision Controller V5.4.3

Ncinterp add the support of 3-D PLT files, it can recognize 2-D or 3-D.

It supports the circle instructions of PLT.

It adds the support of the close cirve instructions.

Weihong Ncstudio Machine Vision Controller V5.4.4

Modify the conditions of the out of limit in the machine programme information box.

When the tools return to the origin, the limit of simulate

Weihong Ncstudio Machine Vision Controller V5.4.5

Modify the mistake of the path name in the files-manage box.

We add the G906 instructions for the synchronization parameter and current position.

Weihong Ncstudio Machine Vision Controller V5.4.6

We improve the limit of software.It avoid sudden stop, so tools can stop slowly.

We modify the radii with the diameter in the box of run-machining-instructions.

Weihong Ncstudio Machine Vision Controller V5.4.7

We add the variables of #SSCURWORKCOOR0, #SSCURWORKCOOR1, #SSCURWORKCOOR2, so we can visit the workpiece coordinate of the current point.

We replace the two-step instruction by one-step instruction.

In the file-manage box, the size of files is put in right order.We use commas to compart every thousand.

Numlock will not affect the short-cut function.

Weihong Ncstudio Machine Vision Controller V5.4.10

We correct the mistake of renovation.

We improve the edit capability of MaskEdit.

Set the shortcut key to be F12.

Weihong Ncstudio Machine Vision Controller V5.4.11

Modify the mistake of delay in starting the spindle.

Modify one mistake of advanced start.

Weihong Ncstudio Machine Vision Controller V5.4.12

Modify the mistake of instruction-run, after the synchronization of G906.

Weihong Ncstudio Machine Vision Controller V5.4.13

Add the automated speed-down of the software limit

There are no remaining mistakes in the software limit.

Weihong Ncstudio Machine Vision Controller V5.4.14

We change the colour of text from black to yellow.

Add _UNIONCONDTION_IMMSTOP.

Weihong Ncstudio Machine Vision Controller V5.4.15

When tools pause, it do not have the problem of speed flop.

Weihong Ncstudio Machine Vision Controller V5.4.16

Add the function of breakpoint-continue and advanced-start in the PLT file.

We just consider the current machining file, when the position of file update.

The biggest speed of the axis Z is setted in the parameter of electric machinery in the manufactory.

There is speed-down in the one-step function.

There is tools-raise(tools-drop)in pause and little-adjustment in NCBoard.

Weihong Ncstudio Machine Vision Controller V5.4.17

It is correct for speed-up or speed-down in the new version.

Weihong Ncstudio Machine Vision Controller V5.4.18

Bug fix: we change to 10 bits in every axis in "direct locate".When we withdraw numbers, it is still 8 bits.

There is no mistake in the delay after we modify pause.

Weihong Ncstudio Machine Vision Controller V5.4.19

It can not power off in Windows 2000 and XP after the setup programme.

We add G992.It is for the function of array.

We modify the mistake of the function CNcKernel::LoadAxisErrorData.

We modify the instruction G00.

We add the instruction of "modify the bit of stop-immediately".

Modify mistake:when the current point is out of the limit, use the function of direct-return-origin.We must not use JOG.

We add the function of the key Escape to the-direct-run window.

We add the action of press-button in the situation of JOG.

When you input wrong parameters in calibrate window, it can not run any more.

We improve the limit-relief-window and it can shift to mode JOG.

Weihong Ncstudio Machine Vision Controller V5.4.20

Modify the temporary emergency-stop function.

Weihong Ncstudio Machine Vision Controller V5.4.21

When the focus window is not 'edit', the small keyboard becomes the manual button.

The keyboard Pause/Break is the shortcut of pause.

ScrollLock is the activate-manual-window-key.

The shortcut of F4 is the shortcut of TraceView.

We improve the arithmetic of manual-keyboard again.

Weihong Ncstudio Machine Vision Controller V5.4.30

Add shortcut key '<', '>' in trace view windows, to support zoom in/out function

Weihong Ncstudio Machine Vision Controller V5.4.32

Add save/load workpiece coordinates function

Weihong Ncstudio Machine Vision Controller V5.4.39

Add mirror machining function

Weihong Ncstudio Machine Vision Controller V5.4.41

Add warning information before expired

Weihong Ncstudio Machine Vision Controller V5.4.44

Add find, replace and other functions and shortkeys in file edit window

Support for simple advertisement version

Weihong Ncstudio Machine Vision Controller V5.4.46

Masked "Reset" function to avoid user's wrong operation (Use CTRL+F12 can call this function)

Weihong Ncstudio Machine Vision Controller V5.4.47

Update the problem: Cannot modify the color in trace view window

Update the problem: No content in inner parameter window

For some reasons, the download was canceled.

Anyone who needs Weihong Ncstudio CNC Machine Vision Controller V5.5.60 ENGLISH Setup,

Feel free to contact us.
