Affordable CNC plasma cutting table STP1325 is equipped with 4x8 table size, which is used for cutting iron, brass, steel, aluminum, copper, alloy and other metals. Now the best 4x8 CNC plasma table for sale at affordable price, free CNC plasma cutting service and support.
CNC plasma cutting table Features
1. CNC plasma cutting table adopts thick square tube welded structure and square rails from Taiwan to ensure running speed and accuracy.
2. The plasma cutting head with water cooling system to cool the material surface quickly, avoid burr and residue.
3. Arc auto adjusting system can choose the best distance between plasma gun and working piece to ensure high accuracy cutting.
4. Power supply adjusts current according to different thickness of the materials to ensure materials cutting without burr.
5. Starfire control system, large capacity storing function, convenient to read and process.
6. FastCAM software with automatic nesting function to save materials.
7. Rotary device for metal tube cutting is optional.
CNC Plasma Cutting Table Technical Parameters
| Model | STP1325 |
| Working area | 1300*2500mm |
| Plasma power | USA Hypertherm Power: 45A, 65A, 85A, 105A, 125A, 200A, |
| Cutting thickness | 0.3-30mm (According to different power) |
| Minimum cutting diameter | Depend on cutting thickness |
| Max cutting speed | 12m/min |
| Transmission | Taiwan Hiwin Square rail and Rack transmission |
| Drive motor | Leadshine stepper motor and driver |
| Control system | Beijing Starfire control system with THC |
| Table | Blade table or Swatooth table |
| Machine frame | General machine frame or Heavy duty frame |
| Working voltage | 220V for machine, 380V for power supply (63A with 220V is available) |
| Optional parts | Rotary device, Flame head, Drilling head, Marking head, Air compressor |
| Consumble parts | Cutting nozzle and electrode |
CNC Plasma Cutting Table Applications
The 4x8 plasma cutting table is suitable for sheet metal cutting, kitchenware, components, decorations industry, ship building, construction equipment, transport equipment, transport equipment, bridge building, wind power, structural steel, agriculture machinery, environmental protection equipment, etc.
CNC Plasma Cutting Table Projects
Different Cutting Capacity of CNC Plasma Cutting Table
Power supply | Cutting thickness | Power supply | Cutting thickness |
China Huayuan Power | USA Hypertherm Power | ||
63A | 8mm | 45A | 8mm |
100A | 15mm | 65A | 10mm |
120A | 20mm | 85A | 12mm |
160A | 30mm | 105A | 18mm |
200A | 40mm | 125A | 25mm |
200A | 30mm | ||
Detail Pictures of CNC Plasma Cutting Table
Chinese Huayuan plasma power supply for CNC plasma cutting machine
America Hypertherm plasma power supply for CNC plasma cutting machine
Starfire control system for CNC plasma cutting machine
Sawtooth Plasma Cutting Table
Tool box with machine delivery of CNC plasma cutting table
STYLECNC Service and Warranty for CNC Plasma Cutting Table
1. one year quality guarantee, the CNC plasma cutting machine with main parts (excluding the consumables) shall be changed free of charge if any problems during the warranty period.
2. Lifetime maintenance free of charge.
3. Free training course at our plant.
4. 24 hours online service and email each day, free technical support. We will reply you in time after receive your problem of the CNC plasma cutting machine.
5. CNC plasma cutting machine has been tested and adjusted before delivery. We will take machine pictures and videos for you after getting your agreement, then we will book a ship.
6. We provide technical services to the door(We have professional engineers to offer machine installation commissioning and maintenance) if customers pay the charges of ticket.
7. If you have any problems during your use. You need our technician to judge where the problem is and help you to solve it. We can provide team viewer and skype with cam till all of your problems solved.
Package and Delivery for CNC Plasma Cutting Table:
We have been cooperating with several big transport agents and shipping companies for long terms, and the goods are packed with standard plywood case for export, it can be transported to you safety as soon as possible.
FAQs for CNC Plasma Cutting Table:
Q: Do you have after-sale service and support?
A: Yes, we are happy to give advice and we also have skilled engineers available across the world. We need your machines running in order to keep your business running.
Q: I am not sure if this CNC plasma cutting machine suitable for my work?
A: Don't worry, just tell me your working materials, max working area and cutting thickness, then I will recommend you the most suitable machine for you.
Q: Are you factory or trading company?
A: We are factory, which manufactures CNC machines with over 10 years experience in CNC machine’s industry.
Q: What other things also need after we bought your CNC plasma cutting machines?
A: With plasma cutting: need plasma power source and air compressor. You can match plasma power supply by yourself, or buy together with the cutter from us, it's optional. If you buy from us, we will connect the wires of plasma power source and CNC plasma cutting machine together, then more conveniently to use.
Q: How can I do if the machine goes wrong?
A: If confronted with such problems, online service is offered, you could contact our after-sale department. Also, we offer engineer delivery service. Please contact us ASAP and don’t try to fix the machine by yourself or someone else. We will response as soon as we can to solve it for you.
We also have CNC plasma cutting table with rotary device to cut metal tubes for option
International Shipping Around the World
All the CNC machines can be shipped worldwide by sea, by air or by international express logistics via DHL, FEDEX, UPS. You are welcome to get a free quotation by filling up the form with name, email, detailed address, product and requirements, we will shortly contact you with the full information including the most suitable delivery method (fast, secure, discreet) and freight.
