Large 3 Axis Gantry Fiber Laser Marking Machine for Sale
The 3-axis fiber laser marking machine comes with a gantry structure that allows the laser beam to move in any direction along the X, Y, and Z axes to engrave on large-format objects and create precise, smooth and clean engravings.
- Brand - STYLECNC
- Model - STJ-9060F
- Table Size - 3' x 2' (36" x 24", 900mm x 600mm)
- Laser Source - Raycus, JPT
- Supplity - 320 Units in Stock Available for Sale Every Month
- Standard - Meeting CE Standards in Terms of Quality & Safety
- Warranty - One-Year Limited Warranty for Entire Machine (Extended Warranties Available for Major Parts)
- 30-Day Money Back Guarantee for Your Purchase
- Global Logistics and International Shipping for You
- Free Lifetime Technical Support for End-Users & Dealers
- Online (PayPal, Trade Assurance) / Offline (T/T, Debit & Credit Cards)
Advantages of Large 3 Axis Gantry Fiber Laser Marking Machine
When the marking range you need exceeds 300*300mm, we can customize the electric mobile table X-axis, XY-axis and XYY-axis for the large gantry fiber laser marking machine.
The three-axis fiber laser marking system adopts a new splicing marking technology. The three axes composed of motors, guide rails, lead screws and other components enable the laser beam to move freely in the X, Y and Z directions.
The large three-axis gantry fiber laser engraver makes up for the uneven defects of traditional marking with its large-format marking capability and high-precision marking capability. Whether it is for industrial or personal use, the large three-axis gantry fiber laser marking machine can meet your various marking needs on metal and some non-metal materials.
Features of Large 3 Axis Gantry Fiber Laser Engraving Machine
• Compared with ordinary fiber laser marking machines, large three-axis gantry fiber laser engravers allow the laser beam to move freely in the three directions of X, Y, and Z, thereby producing exquisite and complex engravings on large-format objects.
• The three-axis motion system consists of motors, guide rails, ball screws and other components, and the working area includes 600*600mm, 900*600mm, 1300*900mm and various customized sizes.
• We use the highest quality laser source with a service life of more than 100,000 hours and maintenance-free.
• The fast galvanometer speed can reach 7000mm/s, which is suitable for high-speed large-format marking.
• Built-in original EZCAD3 control software from Beijing BJJCZ for designing marking patterns, setting marking parameters and controlling three-axis motion.
Technical Parameters of Large 3 Axis Gantry Fiber Laser Engraver Machine
| Model | STJ-6060F | STJ-9060F | STJ1390F |
| Working Area | 600*600mm | 900*600mm | 1300*900mm |
| Output Power | 30W,50W,60W,100W,200W | ||
| Laser Wavelength | 1064nm | ||
| Minimum Line Width | 0.03mm | ||
| Marking splicing accuracy | 0.5mm | ||
| Marking Speed | ≤7000mm/s | ||
| Module type | Stepper or servo motor | ||
| Repeatability Accuracy | ±0.05mm | ||
| Control program | BJJCZ EZCAD3 | ||
| Marking Format | Graphics, text, bar codes, QRcode, automatically date, batch number, serial number,etc. | ||
| Graphic format supported | Ai, plt, dxf, dst, svg, nc, bmp, jpg, jpeg, gif, tga, png, tiff, tif | ||
| Working Voltage | 220V±10%/50Hz or 110V±10%/60Hz or customized | ||
| Unit Power | <0.5kw | ||
| Working Environment | Clean and dust free or dust less | ||
| Working Condition Humidity | 5%-75%, 0-40 degree, free of condensed water | ||
| Laser lifetime | >100000 hours | ||
Details of Large 3 Axis Gantry Fiber Laser Marking Machine
XYZ axis electric moving worktable.
XYYZ axis electric moving worktable is optional.
Large 3 Axis Gantry Fiber Laser Marking Machine electonic cabinet.
BJJCZ EZCAD3 control card.
Applications of Large 3 Axis Gantry Fiber Laser Engraving Machine
Large 3-axis gantry fiber laser marking machines are widely used in the following industries due to their high precision and large-format processing capabilities:
• Marking serial numbers, logos or patterns on large metal sheets, automotive frames and mechanical housings.
• Engraving on large panels (such as stainless steel plates, aluminum alloy plates and some non-metallic plates) for advertising or industrial identification.
• Processing large parts in the aerospace, construction and heavy machinery industries to ensure clear and lasting markings on wide surfaces.
• Keyboard laser marking, commonly used to etch characters, symbols or backlight grooves on keyboard keycaps made of plastic (ABS, PBT), metal or composite materials. Its high precision characteristics enable it to achieve complex designs, such as custom logos or multi-language characters, to meet the diverse aesthetic and functional needs of consumer electronics, industrial control panels and gaming peripherals.
Large 3 Axis Gantry Fiber Laser Engraving & Marking Projects
Packaging & Shipping for Large 3 Axis Gantry Fiber Laser Engraver Machine
Best price and delivery method, guarantee you to receive the cargo as soon as possible.
Packaging Details
• Water-proof plastic film package with foam protection in each corner.
• Solid seaworthy wood box package.
• Save space as much as possible for container loading.
