STM1325 Cheap CNC wood router kit is a type of flatbed wood CNC machine for beginners & machinists in woodworking with 4x8 combo vacuum and T-slot table top.
STM1325 with T-slot Table
STM1325 is a low cost CNC router machine with 4' x 8' size, which is mainly used for popular woodworking such as home door making, cabinet making, woodcrafts making, furnitures and decorations. This is a cheap CNC router kit within your budget.
STM1325 with Vacuum Table
Woodworking industryWooden door, furniture and decoration, Cabinet Making, Wood crafts making, Redwood carving, Archaized furniture and other industries.
Advertising industryDouble face board and scutcheon, department brand, chest brand and the architecture board, ABS brand, acrylic and jade article.
Electronic industryCircuit, insulation materials, LED screen, family appliance shell and model carving.
STM1325 with Mach3 Controller
| Brand | STYLECNC |
| Model | STM1325 |
| Working Area | 1300x2500x200mm |
| Table Size | 4x8 |
| Traveling Positioning Accuracy | ±0.03/300mm |
| Reposition Accuracy | ±0.03mm |
| Table Surface | Vacuum and T-slot Combined (Option: T-slot Table) |
| Frame | Welded Structure |
| X, Y Structure | Rack and Pinion Drive, Hiwin Rail Linear Bearings |
| Z Structure | Hiwin Rail Linear Bearings and Ball Screw |
| Max Power Consumption | 3.0KW (Without Spindle) |
| Max Rapid Travel Rate | 33000mm/min |
| Max Working Speed | 25000mm/min |
| Spindle Power | 3.0KW/6.0KW |
| Spindle Speed | 0-24000RPM |
| Drive Motors | Stepper System |
| Working Voltage | AC380V/50/60Hz, 3PH (Option: 220V) |
| Command Language | G Code |
| Operating System | DSP System (Options: Mach3) |
| Computer Interface | USB |
| Flash Memory | 128M(U Disk) |
| Collet | ER20 / ER25 |
| X,Y Resolution | <0.03mm |
| Software Compatibility | Type3/UcancameV9 Software(Option: Artcam Software) |
| Running Environment Temperature | 0-45 Centigrade |
| Relative Humidity | 30%-75% |
| Packing Size | 3170X2100X1750mm |
| N.W. | 1100KG |
| G.W. | 1280KG |
| Price Range | $4,380.00 - $5,500.00 |
Big steel square tube structure, by seamless welding and hardening treatment, guarantee it to be strong, reliable and durable, with large bearing capacity and long working life.
High-precision ball screw and Taiwan Hiwin linear square rails, which move smoothly to ensure the machining precision. Strong and thick belt for mechanical transmission. The rack with 1.25 helical tooth mold guarantees the quick and high precise transmission.
High power water-cooling spindle works with high speed, safe guarding stability for long-time operation.
Orderly electronic box make the machine keep stable working.
Automatic oil lubrication system.
Tool sensor, it can automatic measure the distance between tool and materials.
Wood CNC Router Accessories.
Identification Plate for STM1325.
4th axis rotary device is optional for cylinder projects.
STM1325-R1
STM1325-R3
As a professional CNC router manufacturer from China, STYLECNC has all kinds of CNC router for sale, such as 3 axis CNC router series, 4th axis CNC router series, 4 axis CNC router series and 5 axis CNC router series. You can get the best CNC router price from manufacturer directly without any CNC router distributor. Don't hesitate any more, tell us your needs to buy a affordable CNC router from STYLECNC.
I bought the STM1325 to upgrade the SainSmarts Genmitsu 3018-PRO with larger 4 x 8 table and higher power spindle kits. Its plug and play, but there is a steep learning curve for the new software came with it (Mach3). I have a lot of experience with CAD, so I can easily make designs and cuts starting out. Ive made some woodworking projects and they all seem to get better than the last one. I cant wait to make more cuts to experience the capabilities of this excellent CNC.
I got my STM1325 with the mentality that I would create a small woodshop making personalized home decor, which I am still working on. Assembly was very easy enough where you can figure it out. The instruction manual offers little for troubleshooting advice, but I was able to find good answers on STYLECNCs website.
I have to say enough good about this CNC machine for wood. I was a bit apprehensive at first, but when I got the wood CNC machine, my fears disappeared. Im not an experts but every part that I know about personally was of good quality, building this machine gave me the knowledge of the mechanics of CNC if I could do it over, I would buy this CNC kit again without any hesitation at all.
Absolutely AMAZING. I am new to the CNC world and this CNC wood machine is incredible for beginners. As a Process Engineer by trade, I can totally give credible feedback in the instructions and assembly process. Perfection! Thanks for making this so easy for me to get into the CNC world.
I was looking for a cnc machine that was big enough for the projects I am working on without costing a fortune. This product is just as sturdy as it looks in the pictures. Assembly was easy enough with the video provided. It does require however that one is mechanically inclined. Whether you want to work with wood or make printed circuit boards the programs included provide a good starting point. So far I have been working with wood to get acquainted with this machine. I am certain it will work fine with printed circuit boards. Note: This CNC machine was packaged well with all pieces intact.
I bought this for to celebrate the 10th anniversary of my workshop in May 21. It was easy for the assembly and software installation. Once I got it set up it did not get much use for a few weeks, COVID-19 in March intervened, I started seriously in April with cabinets making. I am very happy with my purchase does a nice job, and will certainly keep me a good attitude during Coronavirus. In all professinal wood CNC machines, and I had fantastic after-sales service and support from STYLECNC.
Потрясающий фрезерный станок с ЧПУ, все работы выполняются автоматически с высокой скоростью и высоким качеством, я купил станок для изготовления деревянных дверей, и меня сильно удивил.
This is my first overseas buying for a new CNC router machine, it was a great experience, especially the price is much more cheaper than the used CNC router with the same configurations in German, and the 4x8 table size is very suitable for my home door production.
Wife got me this gift for my birthday. Ive used it a couple times and works great. I love it. Ive wanted a CNC router with 4x8 table kit for a long time and this one does not disappoint.
