4x8 ATC CNC Wood Carving Machine with Tool Changer for Sale

Last Updated: 2023-12-22 15:12:55

4x8 ATC CNC wood carving machine is a type of automated wood CNC machine with tool changer for carving and cutting home doors, cabinets, furniture, tables, and other popular woodworking. Now the wood CNC carving machine for sale at affordable price.

4x8 ATC CNC Wood Carving Machine with Tool Changer for Sale
4x8 ATC CNC Wood Carving Machine with Tool Changer for Sale
4x8 ATC CNC Wood Carving Machine with Tool Changer for Sale
4x8 ATC CNC Wood Carving Machine with Tool Changer for Sale
4x8 ATC CNC Wood Carving Machine with Tool Changer for Sale
4x8 ATC CNC Wood Carving Machine with Tool Changer for Sale
4x8 ATC CNC Wood Carving Machine with Tool Changer for Sale
4x8 ATC CNC Wood Carving Machine with Tool Changer for Sale
4x8 ATC CNC Wood Carving Machine with Tool Changer for Sale
4x8 ATC CNC Wood Carving Machine with Tool Changer for Sale
  • Brand - STYLECNC
  • Model - STM1325C3
  • Table Size - 4' x 8' (48" x 96", 1300mm x 2500mm)
5 (58)
US$14200.00 for Base / US$21800.00 for Premium
  • Supplity - 360 Sets / Month Waiting for Sale In Stock
  • Standard - Meet CE Standards in Terms of Quality & Safety
  • Warranting - One (1) Year Limited Warranty for Entire Machine
  • 1-2 Days Handling and 7-30 Days Shipping
  • 30-Day Money Back Guarantee for Your Purchase
  • Free Lifetime Technical Support for End-Users & Dealers
  • Online (PayPal, Trade Assurance) / Offline (T/T, Debit & Credit Cards)

4x8 CNC wood carving machine

4x8 ATC CNC Wood Carving Machine Configurations and Advantages

1. Welded structure by thick profiled steel stabilized under high temperature, ensures minimum distortion, excellent rigidity and powerful strength. All X, Y axis with dust cover, make the working more clean

2. Taiwan LNC control system, separated keyboard control, color LCD display,can alter the parameters and automatically change the tool. Weihong controller for choose.

3. Large torque servo motor makes machine stable running with low noise, high speed and high accuracy.

4. 9KW automatic tool changer spindle makes machine with high precision, long service time and stable movement.

5. Linear guide rail: Taiwan linear guide rail 30mm with high precision, heavy loading and durable.

6. Configured with linear tool magazine of 12 tools the machine can change tools speedy and freely.

7. Auto tool sensor enables the machine compensate the tolerance of the tool length.

8. Vacuum worktable and strong power suction vacuum pump 7.5KW is equipped with this CNC wood carving machine for carpentry.

9. Automatic positioning pop-up pins included which make materials positoning easily and fast.

10. Strong dust collector ensures site cleanliness during the machine operation.

11. Automatic lubricating system, one touch can finish periodic maintenance easily.

4x8 ATC CNC Wood Carving Machine Applications

Furniture: wooden doors, cabinets, plate, office and wood furniture, tables, chair, doors and windows.

The wood products: Three-dimensional wave plate processing, cupboard doors, wooden doors,window processing,video game cabinets and panels, computer table and Plate furniture auxiliary processing.

The advertising industry: Advertising signs, logo production, acrylic cutting, forming system module, a variety of materials advertising the production of decorative products.

Decorate industry: Acrylic, PVC, MDF, artificial stone, organic glass, plastic and soft metals such as copper, aluminum plate engraving and milling process.

Technical Parameters of 4x8 ATC CNC Wood Carving Machine

ModelSTM1325C3
Working Area1300*2500*300mm
Lathe StructureSteel welded steel structure, better than cast iron one
X,Y StructureRack and pinion, gear drive,

Taiwan Hiwin H30 square guide rails

Z StructureTaiwan TBI ball screw,

Taiwan Hiwin H30 square guide rails

Max. Idling Speed50m/min
Spindle9.0 KW air-cooling spindle
Spindle Speed0-24000r/min, variable speed
Working VoltageAC380V/50Hz or AC220V/60HZ
Motor and driverLeadhsine 1500W Servo
CommandG code
Operating SystemLNC control system or Weihong NK300
Tool holderISO30
Cooling ModeAir-cooling
Dust-collect FunctionYes
Work HoldingBy suction or clamp
Tool MagazineLinear style auto tool changer system with 12 pieces of tools

4x8 ATC CNC Wood Carving Machine Features

ATC CNC wood carving machine pictures in factory.

CNC wood carving machine

automatic tool changer of CNC wood carving machine

Vaccum&T-slot combined table.

Vaccum&T-slot combined table

12pcs linear tool storage for ATC CNC wood carving machine.

12pcs linear tool storage for ATC CNC wood carving machine

Weihong NK300 control system.

Syntec control system

4x8 ATC CNC Wood Carving Machine Projects

Wooden doors by CNC wood carving machine

CNC wood carving machine for cabinet doors

CNC wood carving machine projects
