Dual spindles CNC router STM1325-2 is used for three dimensional wave plate processing, cupboard doors, wooden doors, window processing, cabinets and panels, computer table and furniture auxiliary processing.
Advantages of dual spindles CNC router STM1325-2:
Dual spindles CNC router STM1325-2 with two spindles is customized for changing the tools within 2-4 pieces. It's not only economic, but also can realize auto tool change, save the time of manual tool change and improve the working speed and precision. And it can engrave two work pieces at the same time to reach the same effect. What's more, this machine could mirror-sculpture (same engraving path, but in opposite directions) by changing the cables, which is widely used for door carving.
Applications of dual spindles CNC Router STM1325-2:
1. Woodworking industry
Three dimensional wave plate processing, cupboard doors, wooden doors, window processing, video game cabinets and panels, computer table and furniture auxiliary processing.
2. Advertising industry
Advertising signs, logo production, acrylic, plastic cutting, production of decorative materials, forming system module, etc.
Features of dual spindles CNC Router STM1325-2:
1. Whole machine is welded with thick square seamless steel structure; the stability is excellent, not easy to be deformed.
2. Three axis adopt high precision square orbit, X and Y axis adopt rack and pinion transmission, fast working, high efficiency and low cost. Z axis adopts Taiwan TBI ball screw transmission with high precision and long life time.
3. High power spindles have constant power, low noises and super strong cutting force, which improve workingefficiency greatly.
4. Famous brand drivers and motors have characteristics such as powerful strength, fast processing speed.
5. Well compatibility: CAD/CAM designing software e.g. Type 3/ Artcam/ Castmate/ Wentai etc.
6. Has the function of re-carving after break point and power failure.
7. Has the function of forecasting process time.
8. Adopting advanced NCstuido system, convenient operation.
9. Perfect oil lubrication system makes maintenance much easier. And electric limit switch on all axis, make sure machine running well.
10. Independent control box make control easier.
11. We will provide you a set of cutter, and a tool box with other necessary accessories.
Technical parameters of dual spindles CNC Router STM1325-2:
|Body structure||Steel tubes|
|X, Y Structure||rack and pinion drive|
|Z Structure||Ball Screw/option gear wheel|
|X, Y Resolution||<0.01mm|
|Max Moving Speed||32000mm/min|
|Max Engraving Speed||20000mm/min|
|XYZ traveling positioning accuracy||0.03/300mm|
|XYZ repositioning accuracy||0.03mm|
|Spindle power||3kw/4.5kw/5.5KW (can be choices)|
|Table style||T-slot table (option vacuum table)|
|Dust collection||Can add or not|
|Drive type||Stepper (Option servo)|
|Working Dictate||G Code ,HPGL|
|Operating system||DSP control system|
|Flash memory||128M(U Disk)|
Samples of dual spindles CNC Router STM1325-2:
Package of dual spindles CNC Router STM1325-2:
1. Technical supports and suggestions before you order a machine according to your work piece.
2. Professional instruction for the operation of the machine.
3. One year warranty, we will provide the consumable parts at cost price after the warranty period.
4. Our technician will come to your workshop if the problems can not be fixed through Internet or phone communications.
5. 24-hour technical support by email or calling.
